Wire Color Function
Orange* Red LED Control
White
Wiegand: CLK/Data 1/TR+
OSDP: DAT/Data 0/TR-
Green
Wiegand: DAT/Data 0/TR-
OSDP: CLK/Data 1/TR+
*These wires are only used in Wiegand readers.
Important: All wiring methods used must be in accordance with the National Electrical Code, ANSI/NFPA 70.
Max Length to Panel
Wiegand
Length AWG
200' (60 m) 22
300' 20
500' 18
OSDP 9600 Baud Power 12 VDC
Length AWG
1000' 22 AWG Twisted Pair
Current @ 12 V and 25 C
Avg. mA Max. mA
118 169
