32 English
11 Technical Details
TRANSMITTER
Frequency Range: 26.565 – 27.9912 MHz
Modulation Modes AM, FM, SSB
Carrier Suppression: Better than 40 dB below peak output
Unwanted Sideband Suppression: Better than 50 dB below peak output (1
kHz tone)
Spurious Radiation: Better than 50 dB below peak output
Frequency Accuracy: Better than +10 ppm from 0 – 40° C after
15 minute warm up
Maximum FM Deviation: 2 kHz
Output Impedance: 50 ohms
Microphone Impedance: 600 ohms
Power Consumption: 6 amps maximum
Power Output: FM: 4 Watts (Max.)
AM: 4 Watts Average (Max.)
SSB: 12 Watts PEP (Max.)
RECEIVER
Frequency Range: 26.565 – 27.9912 MHz
Tuning Steps: 10 kHz, 500 Hz
Clarifier Range: +/-1.0 kHz
Sensitivity: SSB and AM 0.25uV for 10 dB S+N/N
FM better than 0.3uV for 12 dB SINAD
Minimum discernable signal -135 dBm
Intermediate Frequencies: 1st IF: 10.695 MHz, 2nd IF: 455 kHz
SSB IF: 10.695 MHz
Image Rejection: Better than 70 dB
IF Rejection: Better than 80 dB for all frequencies
Selectivity: -6 dB -60 dB
SSB: 4.2 kHz 8.5 kHz
AM, FM: 6.0 kHz 18 kHz
Noise Blanker: All mode, seven stage high gain type
Dynamic Range: Better than 100 dB
Audio Output Power: 2 watts minimum (into 8 ohms, with less
than 7% THD)
Audio Output Impedance: 8 - 16 ohms
Power Consumption: 500 milliamps
Dimensions: 7.75(L) x 10.75(W) x 2.5(H) Inches
Service Address and Technical Hotline (for units sold in Germany)
PST professional support technologies GmbH
Breitscheider Weg 117a
D - 40885 Ratingen
Contact our service hotline by phone 01805-012204 (14 cent/minute from German
fixed network) or e-mail at alan-service@ps-tech.de .
© 2013 Alan Electronics GmbH
