Alcatel-Lucent OmniSwitch 6800 Series - Dual-Speed Ethernet Transceivers

Dual-Speed Ethernet Transceivers Small Form-Factor Pluggables (SFPs)
page 1-6 OmniSwitch Transceivers Guide June 2007
Dual-Speed Ethernet Transceivers
SFP-DUAL-MM
Dual Speed 100Base-FX or 1000Base-LX Ethernet optical transceiver. Supports multimode fiber and uses an
LC connector.
Connector Type LC
Standards Supported 802.3z, 802.3ah, SFP MSA
Connections Supported 100Base-FX, 1000Base-LX
Fiber Type MMF
Wavelength 1310 nm
Average Power Output 100Base-FX: -20 to -14 dBm
1000Base-LX: -11.5 to -3 dBm
Receiver Sensitivity 100Base-FX: -28 dBm
1000Base-LX: -22 dBm
Transmission Distance 550 m at 1000 Mbps
2 km at 100 Mbps
Maximum Power Output 3 mW
Maximum Pulse Duration 5 ns
Notes
SFP-DUAL-SM10
Dual Speed 100Base-FX or 1000Base-X Ethernet optical transceiver. Supports single mode fiber and uses LC
connector.
Connector Type LC
Standards Supported 802.3z, 802.3ah, SFP MSA
Connections Supported 100Base-FX, 1000Base-LX
Fiber Type SMF
Wavelength 1310 nm
Average Power Output 100Base-FX: -15 to -8 dBm
1000Base-LX: -9.5 to -3 dBm
Receiver Sensitivity 100Base-FX: -28
1000Base-LX: -22
Transmission Distances 10 km
Maximum Power Output 3 mW
Maximum Pulse Duration 5 ns
Notes
