OmniSwitch 6850-P24X OmniSwitch 6850 Series Chassis and Hardware Components
page 2-46 OmniSwitch 6850 Series Hardware Users Guide August 2007
OmniSwitch 6850-P24X
The OmniSwitch 6850-P24X is a stackable edge/workgroup switch offering 20 unshared 10/100/1000
Base-T Power over Ethernet (PoE), two (2) 10 Gigabit XFP connectors, as well as four combo individu-
ally configurable to 10/100/1000 Base-T PoE or 1000 Base-X high speed connections.
The front panel of the OS6850-P24X chassis contains the following major components:
• System status and slot indicator LEDs
• (20) unshared 10/100/1000Base-T PoE
• (4) shared combo 10/100/1000Base-T PoE
• (4) Combo SFP connectors for 1000Base-X connections
• (2) 10 Gigabit XFP connectors
• Console port (RJ-45)
• USB port (USB 2.0)
Note. USB 2.0 is not supported in this release.
