OmniSwitch 6850 Series Chassis and Hardware Components Console Port
OmniSwitch 6850 Series Hardware Users Guide August 2007 page 2-71
Console Port Pinouts
10/100 Ethernet Port – RJ-45 Pinout (non-PoE)
Gigabit Ethernet Port – RJ-45 Pinout
10/100/1000 Mbps Power over Ethernet Port – RJ-45 Pinout
Pin Number Description
1RX+
2RX-
3TX+
4 not used
5 not used
6TX-
7 not used
8 not used
Pin Number Description
1BI_DB+
2BI_DB-
3BI_DA+
4BI_DD+
5BI_DD-
6BI_DA-
7BI_DC+
8BI_DC-
Pin Number Description
1 RX+ (-VDC)
2 RX- (-VDC)
3TX+ (+VDC)
4
5
6 TX- (+VDC)
7
8
