Assembly
Wheel assembly
WARNING!
Always check the mounting plates before assembling
the wheels. Never attach the wheel on a damaged or
loose mounting plate.
The wheels must be assembled on the same height
level. Using a product with wheels assembled on
different height level may cause damage of the
cutting unit (e.g. cutting device, spindle etc.) or an
unsatisfactory result.
1. Align the axle hole of the wheel with one of the three height
adjustment holes in the mounting plate (See Fig B).
2. Insert the knob and tighten it to secure the wheel. Pay
attention to the colour of the bolt. Make sure the colour of the
bolt matches the colour of the mounting plate (See Fig C & D).
3. Repeat the assembly for the other three wheel assemblies.
NOTE! Hand knobs for left side or right side wheels are different!
The two hand knobs with black colour bolts are for the left side
wheels ; The two hand knobs with silver colour bolts are for the
right side wheels. The colour of the bolts match the colour of the
mounting plate on the machine.
To Next Page
