25
AFTER SALES SUPPORT
1300 855 831
support@scheppach.com.au
MODEL: HBS20 PRODUCT CODE: 60339 04/2018
AUS
HBS20 Working instructions
user.
• Collect unused saw bands and store them safely in a dry place. Check for faults
(teeth, cracks) before use. Do not use faulty saw bands!
• Wear suitable gloves when handling saw bands.
• All protective and safety devices must be securely mounted on the machine be-
fore beginning work.
• Never clean the saw band or the saw band guide with a hand-held brush or scrap-
er while the saw band is running. Resin-covered saw bands impair working safety
and must be cleaned regularly.
• For your own protection, wear protective glasses and hearing protection. Wear a
hairnet if you have long hair. Roll up loose sleeves over the elbows.
• Always position the saw band guide as near the workpiece as possible when
working.
• Ensure sufcient lighting in the work area and around the machine.
• Always use the fence for straight cuts to keep the workpiece from tipping or slip-
ping away.
• When working on narrow workpieces with manual feed, use the push stick.
• For diagonal cuts, place the saw table in the appropriate position and guide the
workpiece on the fence.
• In order to cut dovetail tenons and teeth or wedges, bring the saw table into the
corresponding position on the angle scale.
• For arced and irregular cuts, push the workpiece evenly using both hands with the
ngers together. Hold the workpiece with your hands on a safe area.
• Use a pattern for repeated arced or irregular cuts.
• Ensure that the workpiece does not roll when cutting round pieces.
ATTENTION! After every new setting, we recommend performing a test cut, in order
to check the dimensional settings.
• With all cutting processes, the top saw band guide (5) must be positioned as close
as possible to the workpiece.
• The workpiece must always be guided with both hands and kept at against the
saw table (7). This prevents the saw band (21) from jamming.
• Forward feeding should always take place with an even pressure, which is just
sufcient for the saw band to cut through the material with ease without becom-
ing blocked.
• Always use the parallel stop (24) for all cutting processes that it can be used for.
• It is better to perform a cut in a single working step than in multiple steps, which
may require that the workpiece be drawn back. However, if it is not possible to
avoid drawing the workpiece back then the bandsaw must be switched off rst.
