1
2
3
4
Fig. 2
Service hints
Refer to the Overhaul procedure, page 9 for details
Item Description
Inspect the chamber of the rod for roughness.
Damage to seals may occur
Ensure rings are not exposed after tube installation.
Product leakage can occur.
Apply threadlocker to the threads of the valve seat.
Valve seat may loosen.
Do not overtighen the valve seat into the rod.
Distortion of the nylon piston can occur.
