4 901010014 Stannum of cord sotder wire
(lead)
Sn-0.3Ag (excluding copper) 0.00040 Kg
3 101100374 Headphone I/O Board ASSY SP4000 1.00000 SET
4 620020010 STEREO JACK 4PIN ST-015 PBT DIP 1.00000 PCS JK2
4 620020005 STEREO JACK 7Pin MJ-631 DIP 1.00000 PCS JK1
4 628071602 Flat connector with cathode plug
4PIN L=800mm ＃24 one side
4PIN/2.54mm female plug the
other side 4Pin/2.54 contact pin
1.00000 PCS CN1
4 101100375 Headphone I/O Board ASSY (AI
Prat)
SP4000 1.00000 SET
5 501010328 PCB Single layer 22F 1.6mm SP4000 Headphone I/O Board
PCB V01 white silkscreen green
53*43*1.6mm
1.00000 PCS
5 606020002 Ferrite Bead DIP FB35608 8.00000 PCS L1-4 L6-8 L5
3 628071600 Colorized flat cable with cathode
plug
2PIN L=440mm RED BLACK
20＃ 1007 2Pin/2.54 female plug
one side 3.5mm
1.00000 PCS FOR LEFT SPK
3 628071601 Colorized flat cable with cathode
plug
2PIN L=600mm RED BLACK
20＃ 1007 3Pin/2.54 female plug
the 3pin nc one side 3.5mm
1.00000 PCS FOR RIGHT SPK
3 631030248 Velvet 1232*10*1mm crimson 1.00000 PCS
3 631040367 Guide voice canister EVA Dia. 30 thickness 5mm Single
layer viscosity Black
2.00000 PCS
3 631040030 Force-rebounce Glue 15*7*2mm viscosity 3.00000 PCS for IO BOARD
3 631040241 EVA 80*20*1.0mm(LWH) adhesive
with single side
1.00000 PCS for MIAN BOARD
3 626000139 SPEAKER AS YDT717-A8 SPEAKER 2.00000 PCS
3 626000140 Tweeter speaker BESTONE BSQG13-17B4G
8ohm 20W 2.2 uF tweeter
2.00000 PCS
3 29901010501 Pressing sheet SP4-8 DL-1762
RD100902
HIPS Injection black N/A mould
modifictaion with glue
1.00000 PCS
4 298020001 Plastic HIPS 0.00206 Kg
3 631040002 EVA 1310*8*1mm viscosity Black 0.16000 PCS for TWEETER
3 301110022 screw BB 3*6BB Color Zn “+” PWB 2.00000 PCS
3 628110021 cable tie with meson outer Dia.9 inner Dia.φ4.0
T=0.5mm length 55+/-5mm
2.00000 PCS
3 631020017 Black Velvet paper 66*30*0.3mm viscosity 6.00000 PCS
3 628071632 Flat cable with cathode plug
5Pins L=200mm 2468＃24
blue/white one side with 5pins
SM/2.54mm cathode plug
another side with 5pins/2.54mm
latching
1.00000 PCS FOR MB CN25 TO
PEDAL
3 316080028 Keyboard baffle AL spray dumb black silkscreen
white ALESIS
1.00000 PCS
4 316010119 Keyboard baffle SECC T=1.2mm N/A 1.00000 PCS
5 398010004 SECC 1.2mm 0.59000 Kg
3 6330000090 Dual side Gummed paper 5mm*50M(NITTO) 0.02500 ROLL
3 631050010 Gray Sponge 200*15*3mm viscosity 2.00000 PCS for TWEETER
CABLE
3 631050019 Gray Sponge 170*30*3mm viscosity 1.00000 PCS for PEDAL CABLE
3 631050075 Gray Sponge 420*20*3mm viscosity 1.00000 PCS for LEFT SPK
CABLE
3 631050028 Gray Sponge 550*20*3mm viscosity 1.00000 PCS for RIGHT SPK
CABLE
3 631050009 Gray Sponge 70*20*3mm viscosity 1.00000 PCS for CABLE
2 1020502760 Bottom cabinet ASSY SP3000 1.00000 SET
3 20201011401 Bottom cabinet HIPS Black N/A YS9291B
increase pillar after Change
mode
1.00000 PCS
4 298020001 Plastic HIPS 2.37209 Kg
