Alesis Coda User Manual

PN: 002030221 Parent item name : Stage piano
Specification type : LQS8 Measure unit :set
Level Material Coding Subunit Description Subunit specification Qty. Units Remark
1 1020106230 Unpacking part of the Stage
Piano
SP3000(LQS8) 1.00000 SET
2 1020403710 Top cabinet ASSY SP3000(LQS8) 1.00000 SET
3 201030588 Top cabinet HIPS injection black Surface
spray dumb black silkscreen
gray P=420C Alesis_LQS8
1.00000 PCS
4 20101017001 Top cabinet HIPS black N/A LED hole
change small after Change mode
1.00000 PCS
5 298020001 Plastic HIPS 2.07854 Kg
4 652020264
Hard glue anti－alcohol smear
Sand grain black oil
YHE-80A 3216 3.5KG/card
YINHAI
0.03000 Kg
4 652020104
Hard glue anti－alcohol smear
+clear+PUbottom lacquer thinner
SE-036-1 18L/pail 0.06000 Kg
3 215990005 Speaker mesh Left bracket HIPS with black 1.00000 PCS
4 215010095 Speaker mesh Left bracket HIPS Injection molding black N/A 1.00000 PCS
5 298020001 Plastic HIPS 0.09682 Kg
3 215990006 Speaker mesh right bracket HIPS with black 1.00000 PCS
4 215010096 Speaker mesh Right bracket HIPS Injection molding black N/A 1.00000 PCS
5 298020001 Plastic HIPS 0.09682 Kg
3 629020383 Silicone button 1 Rubber black printing carbon
N/A RD130374
6.00000 PCS
3 206010189 Button 2 Clear ABS translucence black
N/A RD101426
1.00000 PCS
3 20801000301 Voice bright knob ABS Injection Black N/A mould
modification after chamfering
1.00000 PCS
4 298010001 Plastic ABS 0.00082 Kg
3 301110024 screw BB 3*8BB Color Zn “+” PWB 49.00000 PCS for FUNCTION
PCB(12) POWER
BOARD（4） MIAN
BOARD（4）IO
BOARD（5）
SPEAKER
BRACKET（10）
HEADPHONE
BOARD（3）FRON
T OF KEYBED
WOOD （7）for
WHEEL ASSY（4）
3 301110028 screw BB 4*10BB black “+” PWB 8.00000 PCS for SPEAKER(8)
3 1012400820 Rotate wheel ASSY SP4000 1.00000 SET
4 628071603 Flat connector grey with cathode
plug
3PIN L=780mm ＃26 one side
3PIN/2.54mm female plug the
other row line split 30 mm end of
the strip line is 3mm
1.00000 PCS
4 6110101900 Rotational Potentiometer H161BN+T2 B10K(55°)
L20FD*12(E) HONG YU
1.00000 PCS
4 631020047 Black Velveteen 40*13.5*0.5 viscosity Black 1.00000 PCS
4 215010103 Rotate Wheel bracket ABS N/A black 1.00000 PCS
4 309070032 Rotate wheel Spring M2/MC70 nickelplate Silvery white inner
Dia.13.5*4N*Φ1.0
1.00000 PCS
4 320070003 Position fixing meson nickelplate Silvery white 8012-3 1.00000 PCS
Bills of Material Component Listing
