4 21301000401 Rotate wheel ABS Injection molding P=433C
N/A increase column after
Change mode
1.00000 PCS
5 298010001 Plastic ABS 0.01133 Kg
4 631990005
Insulation Heat－shrink pipe
Dia. 2 Black 0.07500 M
4 901010015 Stannum of cord solder wire(no
Rohs)
Sn-0.3Ag-0.7Cu φ2.0mm 200g 0.00040 ROLL
4 3020100570 Hexagon Nut M8*0.75mm T=2.0mm OD
Φ=11mm HONG YU
1.00000 PCS
4 3030100350 Gasket ID 8.1mm OD 13mm pachy
0.4mm swedge HONG YU
1.00000 PCS
3 642010443 Lens Black background T=0.8mm
silkscreen gray P=186C P=420C
Windows for transparent black
ALESIS LQS8(SP3000)
1.00000 PCS
3 1010109980 Main board ASSY LQS8 1.00000 SET
4 6040200210 DIP Inductor 15UH +/-20% 4.1A
DCR(Max):31.3mΩ DIP model:
FS1010150M-608317-B
4.00000 PCS L8-11
4 606020002 Ferrite Bead DIP FB35608 2.00000 PCS L7 L18
4 603110092 CAP MYLAR metallization DIP 0.68UF/100V +5%-5% distance
5MM
2.00000 PCS C145 C151
4 603080097 CAP ELECT DIP 1uf/50V +20%-20% 4*7mm DIP 2.00000 PCS C174-175
4 603080004 CAP ELECT DIP 10uf/16V +20% -20% 5*11mm
DIP
7.00000 PCS C1 C7 C38 C40
C130 C166 C168
4 603080058 CAP ELECT DIP 47uf/25V +20% -20% 5*11mm 3.00000 PCS C46 C111 C165
4 603080011 CAP ELECT DIP 100uf/16V +20% -20% 5*11mm 4.00000 PCS C34 C49 C159-160
4 603080034 CAP ELECT DIP 220uf/16V +20% -20%
6.3*11mm DIP
1.00000 PCS C32
4 603080018 CAP ELECT DIP 1000uf/25V +20% -20%
10*20mm
1.00000 PCS C139
4 603080038 CAP ELECT DIP 2200uf/25V +20% -20%
13*20mm DIP
1.00000 PCS C30
4 610070002 Crystal DIP 49S 6MHz (HC-49S) DIP 1.00000 PCS X1
4 628010231 Masculine connector 2Pins/2.54mm Pitch single line
straight prevent fall off
1.00000 PCS CN14
4 628010252 Masculine connector 3Pin/2.0mm Pitch single line
straight DIP
1.00000 PCS CN1
4 628010232 Masculine connector 3Pins/2.54mm Pitch single line
straight prevent fall off
2.00000 PCS CN6 CN15
4 628010296 Masculine connector 5Pins/2.00mm pitch single line
straight prevent fall off
1.00000 PCS CN5
4 628010230 Masculine connector 5Pins/2.54mm Pitch single line
straight prevent fall off
1.00000 PCS CN25
4 628010293 Masculine connector 6Pins/2.00mm pitch single line
straight prevent fall off
1.00000 PCS CN13
4 628010251 Masculine connector 6Pins/2.54mm Pitch single line
straight
1.00000 PCS CN3
4 628010264 Masculine connector 7Pins/2.00mm pitch single line
straight prevent fall off
1.00000 PCS CN9
4 628010329 Mascoline connector 10Pins/2.5mm single elbow with
loss prevention DIP
1.00000 PCS CN2
4 628010327 Masculine connector 12Pins/2.00mm single line bend
feet prevent fall off DIP
1.00000 PCS CN10
4 6280103340 Mascoline connector CKM2008WR-2*10 90°WAFER
2.0
2.00000 PCS CN11-12
4 901010013 Stannum of cord sotder wire
(lead)
Sn-0.3Ag-0.7Cuφ1.0mm
FLUX;2.2%
0.00230 ROLL
4 901010014 Stannum of cord sotder wire
(lead)
Sn-0.3Ag (excluding copper) 0.00500 Kg
4 1010109990 Main board ASSY(SMD Part) LQS8 1.00000 SET
