5 506040362 PCB Dual layer FR4 1.6mm SP4000 main board PCB V01
white silkscreen green
155*97*1.6mm
1.00000 PCS one for two
size:194*155*1.6mm
5 606010009 Ferrite Bead SMD 600R@100Mhz 0603 3.03000 PCS L2 L12-13
5 608010004 Switch Diode SMD IN4148 SOP TYPE SMD 5.02500 PCS D13 D19 D26 D27
D30
5 608040002 Schotthy Diode SMD SS24 2A 40V 1.00500 PCS D31
5 608040026 Schotthy Diode SMD BAS70-05 SOT23 dual common
cathode
1.00000 PCS D14
5 609010006 Transistor SMD BC817-25L SOT-23 NPN 11.05500 PCS Q1 Q3-9 Q12-13
Q16
5 609010053 Transistor SMD MMBT8550D(1500mA) PNP
SOT-23
1.00500 PCS Q15
5 6099900060 Patch mosfet
AOD407 TO-252 Alpha＆Omega
1.00500 PCS Q2
5 603030017 Cap Tantalum ELECT SMD 10uf/6.3V+10%-10% SIZE:2012 1.00500 PCS C171
5 603030003 CAP Tantalum SMD 10uf/10V +10% -10% A 3.2X1.6 2.01000 PCS C18 C58
5 606010006 Ferrite Bead SMD row SMBG3216K4-102 5.02500 PCS FB1-5
5 602030003 Resistor chain SMD 100 ohm(1/16w)+5%-5%
CRN164
15.07500 PCS AR1-12 AR14 AR22-
23
5 602030020 Resistor chain SMD 4.7K ohm(1/16w)+5%-5%
CRN164
7.03500 PCS AR15-21
5 602030005 Resistor chain SMD 10K ohm(1/16w)+5%-5%
CRN164
2.01000 PCS AR13 AR63
5 603010014 CAP CERAMIC SMD 0.01uf/50V +10% -10% 0603
SMD
2.02000 PCS C172-173
5 603010219 CAP CERAMIC SMD 0.1uf/50V +5% -5% X7R 0603 12.12000 PCS C132-134 C136
C141-144 C147-150
5 603010021 CAP CERAMIC SMD 0.1uf/50V +10% -10% 0805 X7R 4.04000 PCS C33 C35 C131 C183
5 603010214 CAP CERAMIC SMD 1uF/50V +10% -10% 1206 X7R 2.01000 PCS C135 C137
5 603010002 CAP CERAMIC SMD 10pf/50V +5% -5% 0603 SMD 2.02000 PCS C13-14
5 603010004 CAP CERAMIC SMD 100pf/50V +5% -5% 0603(NP0)
SMD
59.59000 PCS C61-65 C70-88 C90-
110 C112-115 C138
C162-163 C176-182
5 603010126 CAP SMD 150pf/50V +5%-5% 0603 2.02000 PCS C153 C156
5 603010044 CAP CERAMIC SMD 220pf/50V +5% -5% 0603(NPO)
SMD
4.04000 PCS C154 C157-158
C161
5 603010064 CAP CERAMIC SMD 330pf/50V +5% -5% 0603 NPO 2.02000 PCS C140 C146
5 603010078 CAP CERAMIC SMD 470pf/50V +5% -5% 0603(NPO)
SMD
3.03000 PCS C126 C152 C155
5 603010084 CAP CERAMIC SMD 4700pf/50V +10% -10% 0603
SMD
1.01000 PCS C120
5 603010113 CAP SMD 680pf/50V +5%-5% 0603(NPO) 1.01000 PCS C122
5 602010004 Resistor SMD 0 ohm(1/10w)+5%-5% 0603 9.09000 PCS R3 R6-7 R68 L1 L3
L5 L16 R117
5 602010002 Resistor SMD 0 ohm(1/8w)+5%-5% 0805 4.04000 PCS R1 R46 R129 L6
5 602010010 Resistor SMD 100 ohm(1/8w)+5%-5% 0603 11.11000 PCS R4 R13-15 R18-20
R22-23 R45 R110
5 602010604 Resisitor SMD 100 ohm(1/10w)+1%-1% 0603 2.02000 PCS R101 R118
5 602010021 Resistor SMD 100K ohm(1/16w)+1%-1% 0603 1.01000 PCS R2
5 602010013 Resistor SMD 1K ohm(1/16w)+1%-1% 0603 11.11000 PCS R30 R32 R50 R53
R56 R59 R62 R65
R102 R112-113
5 602010025 Resistor SMD 1M ohm(1/8w)+5%-5% 0603 1.01000 PCS R8
