5 602010393 Resistor SMD 10K ohm(1/10w)+1%-1% 0603 21.21000 PCS R16-17 R21 R24-27
R29 R33 R39 R47-
48 R70-71 R97-100
R120-121 R131
5 602010206 Resistor SMD 1.2K ohm(1/8w)+5%-5% 0603 1.01000 PCS R105
5 602010050 Resistor SMD 1.5K ohm(1/8w)+5%-5% 0603 1.01000 PCS R10
5 602010318 Resistor SMD 18 ohm(1/10w)+1%-1% 0603 4.04000 PCS R34-37
5 602010388 Resistor SMD 2.2 ohm(1/10w)+5%-5% 0603 1.01000 PCS L4
5 602010493 Resistor SMD 2.2K ohm(1/10w)+1%-1% 0603 2.02000 PCS R67 R69
5 602010074 Resistor SMD 22 ohm(1/10w)+5%-5% 0603 6.06000 PCS R49 R52 R55 R58
R61 R64
5 602010622 Resisitor SMD 22 ohm(1/4W)+1%-1% 1206 2.01000 PCS R73 R76
5 602010079 Resistor SMD 220 ohm(1/10w)+5%-5% 0603 1.01000 PCS R28
5 602010086 Resistor SMD 220K ohm(1/8w)+5%-5% 0603 1.01000 PCS R31
5 602010432 Resistor SMD 27 ohm(1/16w)+1%-1% 0603 2.02000 PCS R11-12
5 602010235 Resistor SMD 30K ohm(1/8w)-5%+5% 0603 1.01000 PCS R41
5 602010157 Resistor SMD 4.7 ohm(1/8w)+5%-5% 0805 2.02000 PCS L14 L15
5 602010623 Resisitor SMD 4.7 ohm(1/4w)+1%-1% 1206 4.02000 PCS R74-75 R77-78
5 602010144 Resistor SMD 4.7K ohm(1/16w)+1%-1% 0603 13.13000 PCS R79-81 R83-85 R88-
93 R104
5 602010150 Resistor SMD 47K ohm(1/16w)+1%-1% 0603 3.03000 PCS R103 R109 R111
5 602010197 Resistor SMD 51K ohm(1/10w)+5%-5% 0603 1.01000 PCS R114
5 602010602 Resistor SMD 5.6K ohm(1/10w)+1%-1% 0603 1.01000 PCS R42
5 6010107830 IC SMD RESET IC VDD301SCTA 3V 10-
50mS SOT-23 3PIN Anasem
1.00000 PCS U6
5 6010105850 IC SMD AZ1117H-3.3 SOT-223 1.00000 PCS U11
5 6010101130 IC SMD NJM4580 DUAL LOW NOISE
DMP8 TYPE
1.00000 PCS U10
5 6010106250 IC SMD A2 LQFP144 TYPE 1.00000 PCS U1
5 6010106460 IC SMD MX29GL256EHT2I-90Q 90ns -
40℃ to 85℃ TSOP56 Macronix
1.00000 PCS U2
5 6010109610 IC SMD MX25L8006EM2I-12G 8-PIN
SOP 200mil MXIC
1.00000 PCS U3
5 6010109720 IC SMD STA369BWS PowerSSO-36 ST 1.00000 PCS U7
5 6010106430 IC SMD 78L05 SOT-89 100mA 1.00000 PCS U8
5 6010109290 IC SMD PCM1808 TSSOP-14(TI) 1.00000 PCS U9
5 6010100870 IC SMD 74HC238 SOP TYPE PHI 2.00000 PCS U4-5
5 602010084 Resistor SMD 22K ohm(1/10w)+5%-5% 0603 2.02000 PCS R9 R119
5 603010019 CAP CERAMIC SMD 0.1uf/50V +10% -10% 0603 X7R 32.32000 PCS C2-6 C8-11 C19-21
C27 C29 C31 C36
C39 C43-C45 C47-
48 C59-60 C118-
119 C123 C127
C164 C167 C169-
170
5 603010088 CAP CERAMIC SMD 560pf/50V +5% -5% 0603(NPO)
SMD
1.01000 PCS C41
5 602010053 Resistor SMD 15K ohm(1/16w)+1%-1% 0603 8.08000 PCS R82 R86-87 R94-96
R115-116
3 1011003720 I/O Board ASSY SP4000 1.00000 SET
4 620010006 DC JACK 3Pin DS-210 DIP 1.00000 PCS JK1
4 628110044 INSULOK CALBLE TIES INSULOK 120mm 1.00000 PCS ON JK1
4 628010233 Masculine connector 4Pins/2.54mm Pitch single line
straight prevent fall off
1.00000 PCS CN5
