Alesis Coda User Manual

3 629990120 Deslick silicon gasket φ22.5*3mm black silicon single
layer 3M glue
5.00000 PCS
3 301110024 screw BB 3*8BB Color Zn “+” PWB 8.00000 PCS
3 1020601210 Keyboard ASSY SP3000 88KEYS SPRING
KEYBOARD
1.00000 SET
4 101080018 Keyboard board ASSY 88 FATAR 1.00000 SET
5 628010083 Masculine connector 10Pin*2 straight feet DUAL ROW
PIN Header
2.00000 PCS
LKB：J1 RKB：JP4
5 628060013 Flat cable 3 pin L=50mm #26 1.00000 PCS RKB JP3 TO LKB
JP2
5 901010014 Stannum of cord sotder wire
(lead)
Sn-0.3Ag (excluding copper) 0.00850 Kg
5 901010015 Stannum of cord solder wire(no
Rohs)
Sn-0.3Ag-0.7Cu φ2.0mm 200g 0.00230 ROLL
5 101080061 Keyboard ASSY(AI part) 88 FATAR 1.00000 SET
6 502030008 PCB Single layer 22F 1.6mm Keyboard Left key printing PCB
V05 carbon+ 1678-5
1.00000 PCS 31-1678-3
6 502030007 PCB Single layer 22F 1.6mm Keyboard Right key printing
PCB V05 carbon+ 1679-5
1.00000 PCS 31-1679-3
6 608050001 Switch Diode DIP IN4148 DIP TYPE 176.00000 PCS
LKB：D1-D78
RKB：D79-D176
6 628140007 jump single flat cable 6mm 3.00000 PCS
LKB：J1 RKB：J1
J2
6 398040001 Light copper wire 0.00020 Kg
4 629990109 Round rubber Black non-contact no printing 52.00000 PCS
4 62999010801 Square rubber Black non-contact no printing
single side with three tendon the
after change molde
88.00000 PCS
4 629010057 Conductive Rubber Grey Point carbon 100% long life
Rubber hardness 40
7.50000 PCS
4 309070022 Spring plating white Zn DIA:0.65(ZN-P) 88.00000 PCS
4 21101004701 Bottom seat ABS Black N/A after change
mould
1.00000 PCS
5 298010001 Plastic ABS 0.51500 Kg
5 313010078 keyboard iron bracket Electrolysis sheet Zn plating
Silvery gray
1.00000 PCS
6 398010004 SECC 1.2mm 1.26340 Kg
4 20401000701 Black keyboard ABS Black N/A To die after
modification assembly weights
position size
36.00000 PCS
5 298010001 Plastic ABS 0.01360 Kg
5 298050010 Color seed M5735C 70%ABS250+30%AS
0.5kg
0.30670 g
4 20501003501 A2 key ABS White N/A after the mould
change
1.00000 PCS
5 298010001 Plastic ABS 0.02297 Kg
5 298050003 Color seed M4705B 0.00180 Kg
4 20501003601 A key ABS White N/A after the mould
change
7.00000 PCS
5 298010001 Plastic ABS 0.02112 Kg
5 298050003 Color seed M4705B 0.00160 Kg
4 20501003701 B key ABS White N/A after the mould
change
8.00000 PCS
5 298010001 Plastic ABS 0.02194 Kg
5 298050003 Color seed M4705B 0.00170 Kg
4 20501003801 C8 key ABS White N/A after the mould
change
1.00000 PCS
5 298010001 Plastic ABS 0.02812 Kg
5 298050003 Color seed M4705B 0.00220 Kg
4 20501003901 C key ABS White N/A after the mould
change
7.00000 PCS
5 298010001 Plastic ABS 0.02112 Kg
