Alesis compactkit 4 Service Manual

Circuit Boards
Main Board Schematic-02
8
PAD0 PAD1 PAD2 PAD3
CN4
CN2 CN5
CN6
R33
51K
D5 MBR0530
1
2
R46
47K
1 2
D9
IN4148
C46
0.1u
1
2
R30 100K 1%
C53
100pf
C45
510pf
R29
51K
D6 MBR0530
1
2
R32
47K
D10
IN4148
C47
0.1u
1
2
R34 100K 1%
C48
100pf
C49
510pf
R36
51K
D7 MBR0530
1
2
R37
47K
D11
IN4148
C50
0.1u
1
2
R38 100K 1%
C51
100pf
C52
510pf
R40
51K
D8 MBR0530
1
2
R41
47K
D12
IN4148
C54
0.1u
1
2
R42 100K 1%
C55
100pf
C56
510pf
1 2 3 4
CN6
2.0*4
1 2 3 4
CN2
2.0*4
1 2 3 4
CN5
2.0*4
1 2 3 4
CN4
2.0*4
1
2
R310R
D1
NC/IN4148
1 2
C70
10u 0603
LED0_R
+3.3VA
LED1_R
+3.3VA
LED2_R
+3.3V
+3.3VA
LED3_R
+3.3VA
AD_IN0
AD_IN1 AD_IN2 AD_IN3
GND_ADC GND_ADC GND_ADC GND_ADC
+5V
