Alesis compactkit 4 Service Manual

Parts List
13
+++++ 603010019 CAPCERAMICSMD 0.1uf/50V+10%-10%0603X7R 37.37000 PCS
C2C5~12C14~17C20
C22~24C26C28C37C39
C41~44C46~47C50C54
C59C63~66C69C92~93
+++++ 603010040 CAPCERAMICSMD 22pf/50V+5%-5%0603(COG)SMD 2.02000 PCS C3C4
+++++ 6010109330 ICSMD
AMS1117-3.3SOT-223linearregulater3.3V1A
AMS
1.00000 PCS U4
+++++ 601011208 ICSMD A1built-in2MBytesSDRAMLQFP128 1.00000 PCS U1
+++++ 6010112430 ICSMD
3V16MbitSPIFLASHW25Q16JVSIQ
8pinSOIC208milWinbond
1.00000 PCS U65
+++++ 610030024 TapingCrystalSMD49S 12MHz±20PPM20PF(HC-49S-SMD)WEJ 1.00500 PCS Y1
+++++ 603020003 CAPELECTSMD 100uf/16V+/-20%6.3x5.3mm 5.02500 PCS C31C33C34C36C38
+++++ 603020030 CAPELECTSMD 100uf/6.3V+/-20%5*5.4mm 1.00500 PCS C27
+++++ 603020011 CAPELECTSMD 220uf/16V+/-20%6.3*5mm 1.00500 PCS C25
+++++ 603020008 CAPELECTSMD 470uf/16V+/-20%8*10.5mm 2.00000 PCS C18C19
+++++ 603020002 CAPELECTSMD
10uf/16V+/-20%4.5x3mmTAPE＆REELRV2-
16V
6.03000 PCS C21C29C57~58C60C68
+++++ 603020022 CAPELECTSMD 4.7uf/25V+/-20%4*5.5mm 1.00000 PCS C13
+++++ 603010188 CAPCERAMICSMD 510pf/50V±5%0603SMD 5.05000 PCS C45C49C52C56C62
+++++ 603010200 CAPCERAMICSMD 10uf/10V-20%+20%0603X5R 2.02000 PCS C1C70
+++++ 603010129 CAPCERAMICSMD 1uf/50V+10%-10%0603 2.02000 PCS C71C72
+++++ 601011129 ICSMD RESETICPLD3025CTASOT-23 1.00000 PCS U6
+++++ 609010053 TransistorSMD MMBT8550D(1500mA)PNPSOT-23 1.00500 PCS Q1
+++++ 609010004 TransistorSMD 9014ChighfrequencylowpowerSMD 1.00500 PCS Q2
+++++ 6080400290 SchotthyDiodeSMD MBR0530T10.5A30VSOD-123ON 4.02000 PCS D5~8
+++++ 608010004 SwitchDiodeSMD IN4148SOPTYPESMD 8.04000 PCS D4D9~12D25~27
+++++ 608030005 RectifierDiodeSMD SS5819SMA(DO-214AC) 1.00500 PCS D3
+++++ 603010004 CAPCERAMICSMD 100pf/50V+5%-5%0603(NP0)SMD 4.04000 PCS C48C51C53C55
+++++ 603010009 CAPCERAMICSMD 0.001uf(1000pf)50V+10%-10%0603SMD 1.01000 PCS C61
+++++ 606010015 FerriteBeadSMD BLM18BD102SN10603 3.03000 PCS L1L3L4
+++++ 606010005 FerriteBeadSMD 2012D102B0805SMD 1.01000 PCS L8
+++++ 602010021 ResistorSMD 100Kohm(1/16w)+1%-1%0603 5.05000 PCS R30R34R38R42R141
+++++ 602010393 ResistorSMD 10Kohm(1/10w)+1%-1%0603 12.12000 PCS
R6R16-17R19R44R50R53
R61~62R71~72R88
+++++ 602010005 ResistorSMD 10ohm(1/16w)+1%-1%0603 1.01000 PCS R21
+++++ 602010013 ResistorSMD 1Kohm(1/16w)+1%-1%0603 3.03000 PCS R11R45R47
+++++ 602010024 ResistorSMD 1Mohm(1/16w)+1%-1%0603 1.01000 PCS R7
+++++ 602010578 ResistorSMD 20Kohm(1/10w)+1%-1%0603 1.01000 PCS R54
+++++ 602010433 ResistorSMD 2.7Kohm(1/16w)+1%-1%0603 2.02000 PCS R9R52
+++++ 602010707 ResistorSMD 2.2ohm(1/10w)+1%-1%0603Yageo 2.02000 PCS R13R15
+++++ 602010144 ResistorSMD 4.7Kohm(1/16w)+1%-1%0603 12.12000 PCS
R8R14R55R57R89~90
R20R43R51R56R73R74
+++++ 602010618 ResisitorSMD 51Kohm(1/10W)±1%0603 4.04000 PCS R29R33R36R40
+++++ 602010169 ResistorSMD 56Kohm(1/16w)+1%-1%0603 1.01000 PCS R138
+++++ 602010602 ResistorSMD 5.6Kohm(1/10w)+1%-1%0603 4.04000 PCS R48R49R136R35
+++++ 602030020 ResistorchainSMD 4.7Kohm(1/16w)+5%-5%CRN164 1.00500 PCS AR3
+++++ 602030011 ResistorchainSMD 220ohm(1/16w)+/-10%CRN164chainWORK 4.02000 PCS AR1AR2AR4AR7
+++++ 6010105280 ICSMD BA17805FP3feet 1.00000 PCS U3
+++++ 602010009 ResistorSMD 100ohm(1/16w)+1%-1%0603 5.05000 PCS R1R10R25R59~60
+++++ 602010004 ResistorSMD 0ohm(1/10w)+5%-5%0603 11.11000 PCS
R4-5R28R31R58R63~64
R69L2R39R3
+++++ 602010150 ResistorSMD 47Kohm(1/16w)+1%-1%0603 4.00000 PCS R32R37R41R46
+++++ 602010571 ResistorSMD 1.5Kohm(1/8w)+1%-1%0603 1.00000 PCS R12
+++++ 602030041 ResistorchainSMD 0ohm(1/16w)+5%-5%CRN164 1.00000 PCS AL3
+++ 201030634 Topcabinet
HIPSinjectionblacksprayblacksilkscreenwhite
C“ALESIS”
1.00000 PCS
++++ 20101002408 Topcabinet
HIPSinjectionBlackandremovedofTheLCD
frameribpostion:460*259*133mm(LWH)
1.00000 PCS
+++++ 298020001 Plastic HIPS 0.55620 Kg
++++ 652020391
Hardglueanti－alcoholsmear
+clear+bottomlacquerthinner
AB-59603.5KG/bucket 0.01880 Kg
++++ 652020392
Hardglueanti－alcoholsmear
mattedblack
AB-59183.5KG/card 0.01880 Kg
+++ 206040205 Jointplasticbutton
ABSInjectiongray432Csilkscreen428
outsize:129*72.6*7.2mm
1.00000 PCS
++++ 20601017102 Connectingplasticbutton
ABSInjectionp=432CN/Aafterchangeaddfour
limitcolumn
1.00000 PCS
+++++ 298010001 Plastic ABS 0.02060 Kg
