Alesis iO Hub User Manual

6
1
1
2
3
4
2
1
2
3
4
5
6
7
8
Top Panel
1. Mic/Line Input – Connect a microphone or
line level device (keyboard, sound module,
tape deck, etc.) to this balanced input.
2. Mic/Line/Guitar Input – Connect a
microphone, guitar, or line level device to
this balanced input.
3. Headphone Output – Connect your 1/4"
headphones to this output.
4. Main L/R Outputs – Use standard 1/4"
cables to connect these outputs to a mixer,
speakers, or an amplifier system.
Rear Panel
1. USB Port – Use the included USB cable to
connect iO Hub to your computer. This
connection will power iO Hub.
2. Battery Compartment – Install a 9V battery
here to provide phantom power when iO
Hub is being used with the Apple iPad
Camera Connection Kit.
1
2

Alesis iO Hub Specifications

General

Brand	Alesis
Model	iO Hub
Category	Accessories
Language	English
