Alesis MMT-8 Service Manual

Alesis MMT-8 Service Manual 15
PLS FLIP-UP PANEL (BLK) 9-11-1036 1 W/CASE
PLS CASE BOTTOM 9-11-1006 1
PLS LCD BEZEL 9-11-1009 1 CASE TOP
PLS ALPHA SWITCH CAP 9-11-1011 1 S1
PLS FLIP-UP CHART TOP 9-13-1004 1 FLIP-UP TOP
PLS FLIP-UP CHART BOT 9-13-1005 1 FLIP-UP BOT
PLS REAR PANEL OVERLAY 9-13-1006 1 CASE BOTTOM
RES 100 1/8W 5% 0-00-0101 2 R24,40 MAIN
RES 1K 1/8W 5% 0-00-0102 1 R12 MAIN
RES 10K 1/8W 5% 0-00-0103 5 R2,8,39,41,76 MAIN
RES 100K 1/8W 5% 0-00-0104 2 R1,45 MAIN
RES 1.2K 1/8W 5% 0-00-0122 1 R9 MAIN
RES 1.5M 1/8W 5% 0-00-0155 1 R6 MAIN
RES 2K 1/8W 5% 0-00-0202 1 R11 MAIN
RES 220 1/8W 5% 0-00-0221 21 R46-60,33-38 MAIN
RES 2.2K 1/8W 5% 0-00-0222 4 R26,27,30,31 MAIN
RES 3.3M 1/8W 5% 0-00-0335 1 R15 MAIN
RES 470 1/8W 5% 0-00-0471 10 R43,61-68,75 MAIN
RES 4.7K 1/8W 5% 0-00-0472 21 R3,4,7,10,13,14,16-18,20-23,25,29,42,44,69,77-79 MAIN
RES 47K 1/8W 5% 0-00-0473 1 R5 MAIN
RES 51K 1/8W 5% 0-00-0513 2 R19,70 MAIN
RES 510K 1/8W 5% 0-00-0514 2 R28,32 MAIN
RES 560 1/8W 5% 0-00-0561 4 R71-74 MAIN
RES 10K 9 PIN SIP 0-06-1039 1 R69 MAIN
RUB KEYPAD 9-21-1003 1 CASE TOP
RUB ROUND RUBBER FEET 9-23-1004 4 CASE BOTTOM
RUB RUBBER STRIP 8-3/4 9-23-1007 1 INSIDE CASE BOTTOM
SWT DPDT SWITCH 6-02-0001 1 SI (POWER) MAI
