Alesis MultiMix USB 8 - Page 17

LEVEL PART NUMBE
R
DESCRIPTIO
N
QTY REF
...3
EC10616TS E. CAP 10UF/16V (7MM) 1.000 C333
...3
EC10635TS E. CAPACITOR 10UF/35V 7MM 1.000 C226
...3
EC10650TM E. CAPACITOR 10UF/50V 8.000
C167,169,172,176,182,184,188,192
...3
EC10710TS E. CAPACITOR 100UF/10V 7MM 8.000
C271,272,274,275,277,278,280,281
...3
EC10806TM E. CAPACITOR 1000UF/6V 4.000 C183,187,191,195
...3
EC22450TM E. CAPACITOR 0.2UF/ 50V 8.000
C180,181,185,186,189,190,193,194
...3
EC22450TS E. CAPACITOR 0.22UF/ 50V 4.000 C201,204,207,210
...3
EC22550TS E. CAPACITOR 2.2UF/50V 7MM 4.000 C273,276,279,282
...3
EC22616TSS05 E.CAP 22UF 16V 20% 5MM 2.000 C228,229
...3
EC22710TS E. CAPACITOR 220UF/10V (7MM) 8.000
C289,296,302,303,304,305,306,308
...3
EC47625TM E. CAPACITOR 47UF/25V 8.000
C178,196,197,198,199,224,225,227
...3
EC47625TS E. CAPACITOR 47UF/25V 7MM 39.000
C179,200,202,203,205,206,208,209,211,
C212,215,218,221,230,242,248,254,260,
C267,268,269,270,287,288,294,295,297,
C298,299,300,301,307,309,310,311,312,
C313,314,315
...3
EC47650TM E. CAPACITOR 47UF/50V 8.000
C166,168,170,171,173,174,175,177
...3
MC12350TTF M. CAP 0.012UF/50V(JM3)TF(B) 16.000
C217,223,238,240,244,246,250,252,256,
C258,261,262,264,265,283,290
...3
MC18350TTF M.CAP 0.018UF/50VJ 16.000
C213,214,216,219,220,222,231,232,233,
C234,235,236,237,243,249,255
...3
MC33350TTF M. CAP 0.033UF/50V(JM3)TF(B) 16.000
C239,241,245,247,251,253,257,259,263,
C266,284,285,286,291,292,293
...3
TR2SA970B6 TRANSISTOR 8.000 Q20,21,22,23,24,25,26,27
...3
0-16-1472 CHIP RESISTOR 14.7K (SMD) 4.000 R153,161,164,187
...3
0-16-6041 CHIP RESISTOR 6.04K 1% (SMD) 2.000 R98,101
...3
0-16-7321 CHIP RESISTOR 7.32K (SMD) 4.000 R130,131,132,133
...3
0-16-7501 RESISTOR 7.5K (SMD) 1% 1.000 R230
...3
2-71-0074 IC (TL074) 1.000 IC15
...3
2-71-4580 IC (NJM4580E) 26.000
IC1,2,3,4,5,6,7,10,11,12,13,16,18,19,20,
IC21,23,25,26,28,29,30,31,32,33,36
...3
2-72-0339 I.C. LM339 5.000 IC14,17,22,24,27
...3
2-75-1101 I.C. AL1101 (AD-C 24BIT) 1.000 IC8
...3
2-75-1201 I.C. AL1201 (DAC 24BIT) 1.000 IC9
...3
CS100J5005COG C. CAP 10P (SMD) 2.000 C32,40
...3
CS101J5005COG C.CAP 100P (SMD) 20.000
C2,3,4,13,16,18,19,22,23,30,31,35,36,41,
C42,44,45,97,141,144
...3
CS102K5005X7R CAP 1000P/50V SMD 2.000 C104,105
...3
CS103Z5005Y5V CAP 0.01U/50V/+80,-20(0805)SMD 1.000 C332
...3
CS104K5005X7R CAP. 0.1uF X7R 10% 50V 71.000
C1,12,14,17,21,28,33,34,38,39,43,46,51,
C65,66,67,68,78,79,80,81,82,83,84,85,86,
C87,88,89,90,91,92,93,94,96,100,101,102,
C103,107,111,112,113,114,115,120,121,
C122,123,124,134,135,136,138,139,140,
C142,143,145,148,149,150,151,153,154,
C162
,
163
,
164
,
165
,
318
,
319
...3
CS200J5005COG C. CAP 20P/50V (SMD) 46.000
C5,6,7,15,20,24,25,26,27,29,37,56,57,62,
C63,64,73,74,75,76,77,95,116,117,118,
C119,125,126,127,128,129,130,131,132,
C133,137,146,147,152,155,157,158,159,
C160,316,317
...3
CS331J5005COG CAP. 330P/50V SMD 18.000
C8,9,10,11,58,59,60,61,69,70,71,72,98,
C99,106,108,109,110
...3
CS470J5005COG CAPACITOR 47PF NPO 2.000 C156,161
...3
CS681J5005COG C.CAP 680P (SMD) 8.000 C47,48,49,50,52,53,54,55
...3
DIENLL4148SM DIODE 4148SM SMD 12.000
D1,2,3,4,22,23,24,25,26,27,28,29
...3
RS00018J05 RESISTOR 0 OHM SMD 4.000 R295,298,306,323
...3
RS04718J05 RESISTOR 4.7 OHM SMD 4.000 R68,69,70,71
...3
RS10018J05 RESISTOR 10 ohm SMD 0805 5% 1.000 R411
...3
RS10118J05 RESISTOR 100 ohm 1/10W 5% 2.000 R284,299
...3
RS10218F05 RESISTOR 1K SMD 4.000 R158,159,171,182
...3
RS10218J05 RESISTOR 1K SMD 1.000 R52
...3
RS10318F05 RESISTOR 10K (SMD) 19.000
R27,28,29,30,38,39,40,41,195,196,197,
R198,210,219,236,237,325,390,391
