Alesis MultiMix USB 8 - Page 18

LEVEL PART NUMBE
R
DESCRIPTIO
N
QTY REF
...3
RS10318J05 RESISTOR 10K (SMD) 39.000
R1,2,7,8,9,10,14,15,19,20,24,25,31,35,36,
R37,42,44,45,58,73,79,85,86,91,92,95,96,
R142,146,242,256,280,290,305,319,330,
R331,332
...3
RS10418J05 RESISTOR 100K (SMD) 4.000 R220,222,324,333
...3
RS10518J05 RESISTOR 1M (SMD) 8.000
R231,232,234,235,254,255,260,261
...3
RS12118J05 RESISTOR 120 OHM (SMD) 19.000
R3,4,5,11,16,17,18,23,26,43,49,50,53,60,
R61,67,80,160,199
...3
RS13218F05 RESISTOR 1K3 (SMD) 13.000
R74,75,76,77,81,82,83,84,138,139,140,
R141,238
...3
RS15218J05 RESISTOR 1.5K 1/10W (SMD) 14.000
R163,208,277,278,282,283,291,292,296,
R297,312,313,314,315
...3
RS15318J05 RESISTOR 15K 6.000 R78,110,339,343,345,346
...3
RS18218F05 RESISTOR 1K8 (SMD) 1% 2.000 R392,393
...3
RS20218F05 RESISTOR 2K (SMD) 2.000 R54,62
...3
RS20318J05 RESISTOR 20K (SMD) 0805 5% 18.000
R6,63,64,65,66,117,125,126,127,128,134,
R135,136,137,227,228,229,233
...3
RS22118J05 RESISTOR 220 OHM (SMD) 1.000 R270
...3
RS22218F05 RESISTOR 2K2 OHM 2.000 R12,21
...3
RS22218J05 RESISTOR 2.2K OHM 8.000
R144,145,149,150,151,152,156,157
...3
RS24218J05 RESISTOR 2.4K (SMD)
2.000 R259,264
...3
RS27218J05 RESISTOR 2.7K (SMD) 3.000 R154,155,209
...3
RS27318J05 RESISTOR 27K (SMD) 2.000 R340,342
...3
RS30218F05 RESISTOR 3K (SMD) 1% 2.000 R394,395
...3
RS30318J05 RESISTOR 30K (SMD) 10.000
R33,99,100,106,107,108,111,112,113,115
...3
RS33218J05 RESISTOR 3.3K 1/10W 5% 4.000 R243,244,245,246
...3
RS36218J05 RESISTOR 3K6 SMD 2.000 R205,212
...3
RS43118J05 RESISTOR 430 OHM (SMD) 1.000 R262
...3
RS43218J05 RESISTOR 4K3 (SMD) 2.000 R241,252
...3
RS47018J05 RESISTOR 47 OHM (SMD) 1.000 R114
...3
RS47118J05 RESISTOR 470 OHM (SMD)0805 5% 6.000 R116,118,123,129,258,269
...3
RS47218J05 RESISTOR 4.7K (SMD) 18.000
R55,59,93,97,271,272,273,274,275,276,
R285,286,287,288,336,337,338,344
...3
RS47318J05 RESISTOR 47K SMD 5.000 R265,266,267,268,307
...3
RS51118J05 RESISTOR 510 OHM SMD 8.000
R87,88,89,90,102,103,104,105
...3
RS51218J05 RESISTOR 5.1K (SMD) 33.000
R32,34,56,57,109,239,247,248,249,250,
R253,257,263,279,281,289,293,308,309,
R310,311,316,317,321,322,326,327,328,
R329,334,335,341,347
...3
RS56018J05 RESISTOR 56 OHM SMD 1.000 R147
...3
RS56118J05 RESISTOR 560 OHM 8.000
R172,173,174,175,185,186,188,189
...3
RS56218J05 RESISTOR 5.6K SMD 1.000 R124
...3
RS56318J05 RESISTOR 56K 4.000 R72,94,225,226
...3
RS62118J05 RESISTOR 620 OHM SMD 1.000 R251
...3
RS62218J05 RESISTOR 6K2 (SMD) 2.000 R13,22
...3
RS62318J05 RESISTOR 62K SMD 4.000 R119,120,121,122
...3
RS68118J05 RESISTOR 680 OHM SMD 1.000 R143
...3
RS68218J05 RESISTOR 6.8K SMD 25.000
R46,47,48,51,148,200,201,202,203,204,
R206,207,211,213,214,215,216,217,218,
R221,224,301,302,303,304
...3
RS82218F05 RESISTOR 8K2 SMD 5.000 R181,193,223,294,300
...3
RS91118J05 RESISTOR 910 OHM SMD 19.000
R162,,165,166,167,168,169,170,176,177,
R178,179,180,183,184,190,191,192,194,
R240
...3
TRBC847B TRANSISTOR (SMD) 16.000
Q1,2,3,4,5,6,7,8,11,12,13,14,16,17,18,19
...3
TRBC857B TRANSISTOR BC857B 3.000 Q9,10,15
...3
6-00-0008 POSITION SHAFT ENCODE 1.000 VR11
...3
BALD40210-0 FIXED HOLDER (LED ) 24.000
LED1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,
LED16,17,18,19,20,21,22,23,24
...3
CN0820001101 8P CONNECTOR WIRE 110MM 1.000 TE1
...3
CN0920002001 9P CONNECTOR WIRE 200MM 1.000 TE4
...3
IC4580L IC (NJM4580L) 1.000 IC35
...3
JK-5031-030 DIN SOCKET (XLR) 4.000 MIC1,2,3,4
...3
JK-6353A-02-250 MIC 19.000
J1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16,
J17,18,19
...3
LD-LG2040 LED 3MM GREEN 12.000
LED2,3,11,12,13,14,15,16,17,18,19,20
...3
LDLT0311-41 LED 3MM (RED) 7.000 LED1,5,6,21,22,23,24
