Alesis MultiMix USB 8 - Page 19

LEVEL PART NUMBE
R
DESCRIPTIO
N
QTY REF
...3
LDLY2040A LED 3MM (YELLOW) 5.000 LED4,7,8,9,10
...3
RJGJ107NI RCA CONNECTOR 1.000 RCA1
...3
SWSFPC12MC02 PUSH SWITCH 6.000 SW1,2,3,4,5,6
...3
TE162000602 6P CONNECTOR 2.000 TE2,3
...3
TE812000811 8P CONNECTOR SOCKET 1.000 (TE1)
...3
TE812000911 9P CONNECTOR SOCKET 1.000 (TE4)
...3
VRK10301202 V.RESISTOR 10K AC CC 6.000 VR38,39,40,41,42,43
...3
VRK1030904 V.RESISTOR 10KW 15A 12.000
VR25,26,27,28,29,30,32,33,34,35,36,37
...3
VRK5020902 V.RESISTOR A5K RD 4.000 VR1,2,3,4
...3
VRK50301203 V.RESISTOR B50K CC 6.000 VR9,10,16,17,22,23
...3
VRK50301204 V.RESISTOR 50KW X2 2.000 VR24,31
...3
VRK5030903 V.RESISTOR B50K CC 12.000
VR5,6,7,8,12,13,14,15,18,19,20,21
...3
VRR10302502 V.RESISTOR 10KB 25A 4.000 VR48,49,50,51
...3
VRR10302503 V.RESISTOR 10KB (15A) CC 4.000 VR44,45,46,47
..2 9-79-0354 PCB ASS'Y (POWER) XU1 1.000 16
...3
DI1N4002T5 DIODE IN4002 8.000 D13,14,15,16,17,18,19,20
...3
DIZBZX79C47V ZENEL DIODE 47V 1.000 D21
...3
JW5206T JUMPER WIRE (A.I.) 52MM 1.000 R405
...3
R10018T5 RESISTOR 10 OHM 1/4WCF(M) 1.000 R408
...3
R10318T5 RESISTOR 10K 1/8W CF(W) 1.000 R407
...3
R20318T5 RESISTOR 20K 1/4W CF(M) 1.000 R410
...3
R39418T5 RESISTOR 390K 1/4W 1.000 R409
...3
EC10735TM E. CAPACITOR 100UF/35V 1.000 C322
...3
EC47625TS E. CAPACITOR 47UF/25V 7MM 2.000 C325,331
...3
EC47650TM E. CAPACITOR 47UF/50V
2.000 C328,330
...3
CS104K5005X7R CAP. 0.1uF X7R 10% 50V 2.000 C320,321
...3
CN0320001002 3P CONNECTOR WIRE 100MM 1.000 TE11
...3
EC107100 E. CAPACITOR 100UF/100V 1.000 C329
...3
EC10835 E. CAPACITOR 1000UF/35V 2.000 C323,324
...3
EC476100EM E. CAPACITOR 47UF/100V 2.000 C326,327
...3
IC7805 IC (AN7805) JRC 1.000 IC38
...3
IC7815 IC (7815) 1.000 IC40
...3
IC7915 IC (7915) 1.000 IC39
...3
TE612000202 2P CONNECTOR SOCKET 1.000 (TE10)
...3
TE612000301 3P CONNETOR SOCKET 1.000 (TE7)
...3
TE612000402 4P CONNECTOR SOCKET 1.000 (TE8)
...3
TE612000801 8P CONNECTOR 1.000 (TE9)
...3
TE812000311 3P CONNECTOR 1.000 (TE11)
...3
TRBD239C TRANSISTOR 239C 1.000 IC41
..2 9-79-0355 PCB ASS'Y (USB) XU1 1.000 36
...3
EC10550TM E. CAPACITOR 1UF/50V 4.000 C3U,4U,5U,12U
...3
EC10650TM E. CAPACITOR 10UF/50V 10.000
C1U,2U,6U,7U,8U,9U,10U,11U,13U,14U
...3
EC22616TM E. CAP 22UF/16V 1.000 C34U
...3
EC33450TS E. CAPACITOR 0.33UF/50V 1.000 C30U
...3
2-71-0072 IC (TL072) 2.000 IC1U,3U
...3
CS102K5005X7R CAP 1000P/50V SMD 2.000 C24U,25U
...3
CS104K5005X7R CAP. 0.1uF X7R 10% 50V 11.000
C27U,31U,32U,33U,C36U,C37U,C38U,
C39U, C40U,C41U, C42U
...3
CS182K5005X7R C.CAP 1800P (SMD) 2.000 C15U,16U
...3
CS220J5005COG C.CAP 22PF/50V/+-5% (0805 SMD) 2.000 C21U,22U
...3
CS221J5005COG CAPACITOR 220P SMD 2.000 C17U,18U
...3
CS331J5005COG CAP. 330P/50V SMD 4.000 C19U,20U,28U,29U
...3
CS472J5005COG CAP 4700PF COG 50V 5% 2.000 C23U,26U
...3
DISDBAT54CSM SCHOTTKY DIODE 1.000 Q2U
...3
ICBA033FP IC (BA033FP) 1.000 Q1U
...3
ICPCM2900E IC (PCM2900E) 1.000 IC2U
...3
RS00018J05 RESISTOR 0 OHM SMD 1.000 R31U
...3
RS10018J05 RESISTOR 10 ohm SMD 0805 5% 1.000 R22U
...3
RS10118J05 RESISTOR 100 ohm 1/10W 5% 4.000 R5U,8U,10U,11U
...3
RS10418J05 RESISTOR 100K (SMD) 2.000 R27U,28U
...3
RS10518J05 RESISTOR 1M (SMD) 1.000 R9U
...3
RS12318J05 RESISTOR 12K (SMD) 2.000 R23U,26U
...3
RS15218J05 RESISTOR 1.5K 1/10W (SMD) 3.000 R19U,20U,21U
...3
RS18318J05 RESISTOR 18K SMD 2.000 R1U,2U
...3
RS22018J05 RESISTOR 22 OHM (SMD) 2.000 R12U,13U
...3
RS27318J05 RESISTOR 27K (SMD) 2.000 R3U,4U
...3
RS39218J05 RESISTOR 3.9K (SMD) 4.000 R6U,7U,24U,25U
