4) Press the VALUE buttons to select the desired recorded Sample signal level.
The range is 0 to 99 with 0 being off.
PANNING AND TREMOLO
MODULATION
Auto Panning and Tremolo modulation of the EQ output has been added to the
EQ->PITCH->DELAY->REVERB and 5 BAND EQ->PITCH->DELAY
configurations.
Auto Panning allows a signal that has first been routed through the EQ section of
either of the above configurations to automatically pan from side to side at a
selectable rate. Please note that the effect will only be heard when both the left
and right outputs of the Quadraverb are in use.
Tremolo Modulation means that a signal that has first been routed through the
EQ section of either of the above configurations will vary in volume at a selected
rate. Both the depth and rate of the Auto Panning and Tremolo Modulation can
be varied and/or modulated by any MIDI modulation source.
SELECTING THE PANNING OR TREMOLO
CONFIGURATION
Auto Panning or Tremolo Modulation is accessed through the EQ->PITCH-
>DELAY->REVERB or 5 BAND EQ->PITCH->DELAY configurations.
To select either configuration, first press the
CONFIG button, then press the
VALUE buttons until the display reads:
CONFIGURATION:
EQ>PCH>DL>REVERB
or
CONFIGURATION:
5BAND EQ>PCH>DL
The block diagram of this configuration is as follows:
FIGURE 5
EQ->PITCH->DELAY->REVERB BLOCK DIAGRAM
