2
BOX CONTENTS
SamplePad
Power adapter
Quickstart Guide
Safety Instructions & Warranty Information Booklet
CONNECTION DIAGRAM
TOP PANEL FEATURES
1. PAD – Strike these single-zone pads with a drumstick.
2. VOLUME – Adjusts the volume level.
3. LCD – Displays the current parameters and other
operations.
4. VALUE +/- – Decreases or increases the value of each
parameter.
5. SELECT +/- – Moves up or down through the available
modes.
6. PAD INDICATORS – An LED in this section will
illuminate when that pad is struck.
7. SD CARD SLOT – Plays a .Wav file from the SD Card
WARNING: Put on your headphones or turn on your
speakers only AFTER
turning on the SamplePad.
* Sold separately
OR
HEADPHONES*
SPEAKERS*
POWER
MODULE
MOUNT*
KICK PAD*
("TRIGGER")
FOOTSWITCH*
("SWITCH")
1
2
3
4
5
6
7
