Alesis SampleRack - User Guide Introduction; Box Contents; Support Information; Connection Diagram

3
DC IN
9V DC 500mA
SNARE TOM 1 TOM 2 TOM 3 CRASH 1 CRASH 2 RIDE HI-HAT PEDAL PEDAL
User Guide (English)
1. Make sure all items listed in the Box Contents are included in
the box.
2. READ SAFETY INSTRUCTION BOOKLET BEFORE USING
THE PRODUCT.
3. Study the connection diagram.
Support
For product registration, visit alesis.com.
For the latest information about this product (system requirements, compatibility information, etc.), visit
alesis.com/samplerack.
For additional product support, visit alesis.com/support.
Connection Diagram
* Sold separatel
y
Power
Kick
Pad*
Footswitch*
Box Contents
 SampleRack
 Power Adapter
 User Guide
 Safety Instructions & Warranty
Information Booklet
Computer*
External MIDI Device
(Keyboard, Drum Module,
etc.*)
Triggers*
Speaker*
Hi-Hat Pedal*
