Description of Controls
STUDIO 24 REFERENCE MANUAL 7 7
HIGH AND LOW
These are standard shelving “treble and bass” tone controls. The HIGH knob range is
+/- 15 dB at a fixed frequency of 12 kHz. This means that frequencies above 12 kHz
will be boosted or cut by the same amount , and frequency response between 1 kHz
and 12 kHz will gradually rise or fall to the shelving point. The LOW knob range is
+/- 15 dB at a fixed frequency of 80 Hz. This means that frequencies below 80 Hz will
be boosted or cut by the same amount, and frequency response will gradually rise or
fall from 80 Hz to about 1 kHz.
