5Maintenance
Formaintenanceinstructionsfromsuppliers,seechapter8Appendix.Always Always
Always
ensurethatmountingisaccordingtochapter6
Technicaldata.Ensuretotallycleansurfacesduringmounting-alsoremoveremainingloctiteresidueonthreads.Always Always
Always
refer
totighteningtorquesinchapter6Technicaldata.
Step Step
Step
5 5
5
ReleasethegearmotorfromtheAgitator.Refertosupplier
instructions.
CAUTION CAUTION
CAUTION
ThereisaNord-lock®washermountedonthegearfastening
theshaft.
Thewasherconsistsoftwopartsattachedtoeachotherwith
somesiliconeasshownonthepicture.Itisimportantthatthe
twopartsarepositionedasshown.
Step Step
Step
6 6
6
Liftupthedriveunitandpullitaway.
Step Step
Step
7 7
7
Replacementdriveunit.
Step Step
Step
8 8
8
UseLoctite®243beforefasteningscrews.
Always Always
Always
refertotighteningtorquesinchapter6Technicaldata.
Step Step
Step
9 9
9
Mountdriveunitreverseasdismantling.
