5Maintenance
Formaintenanceinstructionsfromsuppliers,seechapter8Appendix.Always Always
Always
ensurethatmountingisaccordingtochapter6
Technicaldata.Ensuretotallycleansurfacesduringmounting-alsoremoveremainingloctiteresidueonthreads.Always Always
Always
refer
totighteningtorquesinchapter6Technicaldata.
5.10Replacementofshaftseal,typeD
NOTE NOTE
NOTE
Toreplacesealseasier,usedetergent.
Ensuresubsequenttosealreplacement,thatallsealfacesaretotallyclean,usingalcohol.
Positionsreferredtoinfollowinginstructionscanbeseenintheaboveillustration.
NOTE NOTE
NOTE
Ifpossible,always always
always
dismantletheAgitatorfromthetankbeforedismountinganyparts.
Step Step
Step
1 1
1
1.DismantleAgitatorfromweldingflange.
2.LiftupAgitator
Step Step
Step
2 2
2
1.Removeflushconnections(21).
2.Removeguardsfromlantern.
