5.11Replacementofshaftseal,typeDC
NOTE NOTE
NOTE
Toreplacesealseasier,usedetergent.Ensuresubsequenttosealreplacement,thatallsealfacesaretotallyclean,usingalcohol.
Positionsreferredtoinfollowinginstructionscanbeseenintheaboveillustration.
Step Step
Step
1 1
1
1.DismantleAgitatorfromweldingflange.
2.LiftupAgitator.
Step Step
Step
2 2
2
1.Removeflushconnections(17).
2.Removeguardsfromlantern.
