5Maintenance
Formaintenanceinstructionsfromsuppliers,seechapter8Appendix.Always Always
Always
ensurethatmountingisaccordingtochapter6
Technicaldata.Ensuretotallycleansurfacesduringmounting-alsoremoveremainingloctiteresidueonthreads.Always Always
Always
refer
totighteningtorquesinchapter6Technicaldata.
Step Step
Step
5 5
5
1.Pulloutshaft(4)includingbearings(pos8,9).
2.Removeo-rings(7,11).
Step Step
Step
6 6
6
1.Secureshaft(4),withoutcausingsurfacedamagetoit.
2.Removecoupling(12)byturningittheoppositedirection
indicatedbyarrowonnameplate
Step Step
Step
7 7
7
1.Removebearing(8).
2.Removeinnercirclip(14)carefully.Usesuitedpliers.
3.Removebearing(9).
Step Step
Step
8 8
8
1.Replacebearings(8,9)ando-rings(6,7,11).
2.Assemblyofbearingframeisreverseasdismantling.
CAUTION CAUTION
CAUTION
Onlyapplyforcetoinnerbearingringswhenmountingbearingsondriveshaft.
46
