5Maintenance
Formaintenanceinstructionsfromsuppliers,seechapter8Appendix.Always Always
Always
ensurethatmountingisaccordingtochapter6
Technicaldata.Ensuretotallycleansurfacesduringmounting-alsoremoveremainingloctiteresidueonthreads.Always Always
Always
refer
totighteningtorquesinchapter6Technicaldata.
Step Step
Step
5 5
5
Removeoutercirclip(10)carefully.Usesuitedpliers.
Step Step
Step
6 6
6
1.Pulloutdriveshaft(4)includingbearings(8,9).
2.Removeo-ring(7)
Step Step
Step
7 7
7
1.Removeinnercirclip(14)carefully.Usesuitedpliers.
2.Removerbearings(8,9).
Step Step
Step
8 8
8
1.Replacebearings(8,9)ando-rings(6,7,11,15).
2.Assemblyofbearingframeisreverseasdismantling.
CAUTION CAUTION
CAUTION
Onlyapplyforcetoinnerbearingringswhenmountingbearingsondriveshaft.
Onlyapplyforcetoouterbearingringswhenmountingdriveshaftwithbearingsintobearingframe.
