5Maintenance
Formaintenanceinstructionsfromsuppliers,seechapter8Appendix.Always Always
Always
ensurethatmountingisaccordingtochapter6
Technicaldata.Ensuretotallycleansurfacesduringmounting-alsoremoveremainingloctiteresidueonthreads.Always Always
Always
refer
totighteningtorquesinchapter6Technicaldata.
Step Step
Step
5 5
5
1.Pulloutdriveshaft(4)includingbearings(pos8a,9).
2.Pulloutcirclip(12)orletitstayinbearingframe.
NOTE NOTE
NOTE
Outerbearingring(8b)shouldstayinbearingframe
Step Step
Step
6 6
6
1.Removeuppercirclip(13)carefully.Usesuitedpliers
2.Pushout,usingapplicabletool,theouterbearingring(8b).
3.Removeo-rings(7,11).
Step Step
Step
7 7
7
1.Removeinnercirclip(14)carefully.Usesuitedpliers.
2.Removebearings(8a,9)
Step Step
Step
8 8
8
1.Replacebearings(8a,8b),(9)ando-rings(6,7,11).
2.Assemblyofbearingframeisreverseasdismantling.
CAUTION CAUTION
CAUTION
Onlyapplyforcetoinnerbearingringswhenmountingbearingsondriveshaft.
Onlyapplyforcetoouterbearingringswhenmountingdriveshaftwithbearingsintobearingframe
44
