5Maintenance
Formaintenanceinstructionsfromsuppliers,seechapter8Appendix.Always Always
Always
ensurethatmountingisaccordingtochapter6
Technicaldata.Ensuretotallycleansurfacesduringmounting-alsoremoveremainingloctiteresidueonthreads.Always Always
Always
refer
totighteningtorquesinchapter6Technicaldata.
Step Step
Step
5 5
5
Removerotarysealpartfromshaft.
Step Step
Step
6 6
6
Removestationarysealpartando-ringfrommountingflange.
Step Step
Step
7 7
7
1.Removescrews.
2.Removeretainerring.
3.Removerspringandstationarydrivering.
Step Step
Step
8 8
8
1.Replaceallsealparts.
2.AssembleAgitatorreverseasdismantling.
