7Partslistsanddrawings,servicekitsandtools
AgitatortypeALS/ALB,maincomponents-driveend
Parts Parts
Parts
list list
list
Pos.
Qty
Denomination
1o1
GRgearmotor,hollowshaft
2o
1
GPgearmotor,hollowshaft
3o
1
GRgearmotor,outputshaft
4o1
GCgearmotor,outputshaft
5♦
1
BearingframeB20,B25,B25/30,
B35,B35/40,B45,B45/50,B55,
B55/60
6♦
1
Bearingframe,BC160/35,
BC160D/30,BC160DH/30
7♦
1
ShaftsealtypeR
8♦
1
ShaftsealtypeG
9♦
1
ShaftsealtypeV
10♦
1
ShaftsealtypeS
11♦1
ShaftsealtypeS3
13
1
O-ring
1
O-ring
1
O-ring
1
O-ring
16oX
Screw
17o1
Weldingflange
18o
1
Mountingflange,standard
19o
1
Mountingflange,raised
20o
X
Stud
21oX
Capnut
22oXWasher
23oX
Screw
24o
1
Washer,NordLock
25o
1
Fixingelement
26o
1
Lantern,complete
27o
1
Driveunitflange
34o
1
Flatgasket
35o
1
Coupling
36o
1
Motorandshaftunit
37o
1
Motor
38♦
1
ShaftsealtypeD
39♦
1
ShaftsealtypeDC
¬
ArticlenumberavailableuponrequestbyserialnumberorarticlenumberoftheAgitator.
◆
ArticlenumberistobefoundintheSparepartmanualESE03339,availablefromtheon-lineAlfaLavalproductcatalogue
AnytimeortheCloseathandsparepartcatalogue.
X
QuantitymayvarydependingonAgitatortype,willbeinformeduponrequest.
