Maintenance English
Plate Heat Exchanger 17
eng
Regasketing
Clip-on gaskets
Open the plate heat exchanger according
to page 9, and remove the plate that is to
have a new gasket.
Remove the old gasket.
Assure that all sealing surfaces are dry,
clean and free of foreign matters.
Attach the clip-on gasket to the plate. Slip
the gasket prongs under the edge of the
plate.
Proceed with the next plate to be regasket-
ed until all plates in need of regasketing
are done with.
Close the plate heat exchanger according
to page 14.
Clip-AD gaskets (MX25)
The Clip-AD gasket represents a system with the
conventional Clip-on fastening around the ports and
fastening by means of adhesive tape along the sides
of the plates.
The use of the adhesive tape (GC1) is a simple way
to obtain secure gasket positioning. It is adhered to
the gasket groove by means of a special tape pistol,
making it easy to apply the tape exactly where want-
ed.
Open the plate heat exchanger according
to page 9, and remove the plate that is to
have a new gasket.
Remove the old gasket.
It is not necessary to remove old tapes as
the film is very thin. Make sure, however,
that the gasket groove is clean and dry.
Adhere tape, using the pistol.
Note!
Make sure the two gasket prongs are in
correct position.
