Alfa Laval M6 User Manual

Operati on
Step 3
If there is a vent valve installed at the exit, make sure it is fully
open.
Step 4
Increase the flo w rate slowly.
Step 5
O pen the air vent and star t the pump.
A
Step 6
O pen the valve slowly.
Note!
Avoid rapid tempera ture chan ges in the heat exchanger.
With media te mperatures over 100°C, slowly increase
the temperature, preferably at least for one ho ur.
Step 7
When all the air is expelled, close the air vent.
Step 8
Repeat Step 1 to Ste p 7 for the second media.
Docum
en t ID
Langu
age
Editi
on
16 Instruction Manual - Plate Heat Excha ngers 3490010217 EN 2016-06

Alfa Laval M6 Specifications

General

Type	Plate Heat Exchanger
Gasket Material	NBR, EPDM, Viton
Model	M6
Connections	Flanged
Application	HVAC
Frame Material	Carbon Steel
Temperature Range	-20°C to 150°C
Plate Thickness	0.5 mm
Plate Material	Stainless Steel
