K TIME DIFFERENCE TO BEST TIME
The difference between the former fastest time and the last lap is shown in this « ligne K » (a maximum of 9 seconds and 99
hundredths of a second; beyond this, three small dashes appear). Example : (Figure 3)
L LAP NUMBER
This displays the total number of laps completed.
4° READING THE RESULTS AND CONFIGURATIONS
The results and most important instructions are found
in Menu 1, which is divided into 5 Sub-Menus.
- 1 - MAIN RECALL
- 2 - RECALL, RESET and Selection between 5 ENGINE RUNNING TIME COUNTERS
- 3 - PRINT VIA PC
- 4 - RESET
- 5 - ACCESS To the 2
nd
MAIN MENU
ENGINE “RPM” GRAPHICS and SYSTEM CONFIGURATION
The Engine “RPM” Graphics and System Configuration are found
in 2
nd
Main Menu, which is divided into 7 Sub-Menus.
- 6 - ENGINE “RPM” GRAPHICS
- 7 - ENGINE RPM TYPE SETTINGS: M or D
- 8 - ENGINE STROKE TYPE SETTINGS (IGNITION:1, 2, 4, 8 STROKE)
- 9 - NUMBER OF MAGNETIC STRIPS SETTINGS: 1, 2, or 3
- 10 - TEMPERATURE SENSOR TYPE and MEASUREMENT UNIT SETTINGS:
- 11 - ENGINE TEMPERATURE ALARM SETTINGS.
- 12 - RESET TO FACTORY DEFAULT SETTINGS.
NOTE : With the left push button (No1), we scroll from one sub-menu to the other. With the right push button we make a
selection in the sub-menu. Remember : to make it easier, the sub-menu number is always indicated on the display except for
sub-menu 1 “MAIN RECALL”
Unit Working Flowchart for the 2 Main Menus and the 12 Sub-Menus
The system must be in the STOP mode :
1
st
Impulse to the left button; this takes you to the Main Menu 1,
sub-menu - 1 - :
MAIN RECALL “recall”
The screen displays the data recorded during the best lap. For each additional impulse on the right button the ALFANO will
display the data starting from the first lap.
Reading of the results of the split times
a) If the time between pressing the right push button is shorter than 3 seconds only the lap times are shown and not the cycles
of the split times.
b) If the time between pressing the right push button is longer than 3 seconds the cycle for the split times begins. Example
(figure 4).
2
nd
Impulse to the left button: this takes you to the Main Menu 1,
sub-menu - 2 - :
ENGINE RUNNING TIME COUNTER “motor”
“MOTOR” is displayed with the serial number of your ALFANO.The system has 5 counters. The counters show the
running times of each engine in hours and minutes. Select the desired counter with the right button. Keep the right button
pressed to reset the counter to zero.
3
rd
Impulse to the left button: this takes you to the Main Menu 1,
sub-menu - 3 - :
PRINT “print”
