Algam Lighting SPIDER TRI 912 - Menu Operating Instructions

P.18
FUNCTION DESCRIPTION
1 MENU
To go forward in the selected functions
or go back the last layer menu
2
To go forward in the selected functions
or increase parameter
3
To go backward in the selected functions
or reduce parameters
4 ENTER To go into the next layer menu
2 3 41
-
MENU OPERATING INSTRUCTION
MENU DISPLAY FUNCTION
Addr A001-A512
DMX address setting
CHnd
16CH
16CH setting
24CH
24CH setting
48CH
48CH setting
SLnd
Auto
Master auto mode
Soun
Master sound mode
SL 1
DMX512 Mode
SL 2
Slave Mode
SHnd
SH 0
Effect 0 (Recommended)
SH 1
Effect 1
SH 2
Effect 2
SH 3
Effect 3
SEnS
0-100
Adjust the sensitivity of sound
bLnd
bLAc
No DMX signal
Auto
Auto mode without DMX signal
Soun
Sound mode without DMX signal
HLod
Remain last status from Console. No DMX signal
bALA
rEd
Red dimming
GrEn
Green dimming
bluE
Blue dimming
uHil
White dimming
rPAN
no
X motor forward
YES
X motor reverse
rTiL
no
Y3 motor forward
YES
Y3 motor reverse
RSET
YES
System reset
