Algam Lighting SPIDER TRI 912 - 16 Channel; DMX Protocol

P.19
DMX PROTOCOL
CHANNEL VALUE DESCRIPTION
CH1
0-255 X axis Running
CH2
0-5 No function
6-127 X axis innite forward rotation
128-255 X axis innite reverse rotation
CH3
0-255 Y1 motor running
CH4
0-255 Y2 motor running
CH5
0-255 Y3 motor running
CH6
0-255 Motor speed adjustment
CH7
0-255 LED total dimming
CH8
0-9 No function
10-249 Strobe from slow to fast
250-255 No function
CH9
0 No function
1-7 Gradual change effect
8-140 Auto effect (Recommended)
141-255 Sound effect
CH10
0-15 No function
16-44 Effet automatique 0 (recommandé)
45-74 Auto Effect 1
75-104 Auto Effect 2
105-128 Auto Effect 3
129-157 Sound Effect 0 (Recommended)
158-187 Sound Effect 1
188-217 Sound Effect 2
218-255 Sound Effect 3
CH11
0-255 Speed adjustment
CH12 0-255 Red dimming
CH13
0-255 Green dimming
CH14 0-255 Blue dimming
CH15
0-255 White dimming
CH16
250-255 Reset
16 CHANNEL
