TECHNICAL SPECIFICATIONS
Pressure Relief Valve Set point: 17.24 barg (250 psig)
Heat Exchanger: MAWP: 17.24 barg @ 149 ºC (250 psig @ 300 ºF)
MDMT: -29 ºC @ 17.24 barg (-20 ºF @ 250 psig)
Hydrostatic Test Pressure: 25.86 barg (375 psig)
PED: SEP (Sound Engineering Practice) for models Z25 - Z50
Category I for models Z100 - Z150
Electrical: Voltage: 100 – 277 VAC 1PH (All models)
Voltage: 240 – 480 VAC 3PH Wye (Z100 and Z150 only)
Frequency: 50/60Hz
Circuit breaker: See Electrical Specifications in the Appendix
Ambient temperature -4 ºF to +122 ºF (-20 ºC to +50 ºC)
rating:
Hazardous Area Rating:
2460 II 2 G
DEMKO 19 ATEX 2083X
II 2 G Ex db IIA T3 Gb
IECEx UL 19.0034X
Ex db IIA T3 Gb Class I, Division 1, Group D, T3
Enclosure Rating: Type 4 (shell not required)
Fasteners: M10 x 50 mm CLASS 8.8, Min. Yield strength 640 MPa
Seal-off: ¾” Male NPT Thread
LPG VAPORIZER
FOR HAZARDOUS
