2. GRAPHIC SYMBOLS
Some instructions in the manual and on the device are highlighted by graphic symbols to draw the reader’s
attention to the operational dangers. The following graphic symbols are used:
DANGER!
This warning indicates the possible presence of voltage exceeding 1kV on the marked
terminals (even if for short periods).
WARNING!
This warning indicates the possible occurrence of an event which may cause a serious
accident or considerable damage to the device if suitable precautionary countermeasures
are not taken.
ATTENTION!
This warning indicates the possible occurrence of an event which may cause a light accident
or damage to the device if suitable precautionary countermeasures are not taken.
NOTE. This warning indicates important information which must be read carefully.
3. DESCRIPTION
UPT210 is a digital meter able to measure the electrical parameters on three-phase systems.
It provides accurate measurements even by distorted waveform.
LCD display provides the three-phase quantities. The working parameters can be easily set up by instrument
keypad.
UPT210 is a compact, cost effective meter operating both as a stand-alone device or as an integral part of
a more extensive energy monitoring and management network.
UPT210 replaces multiple analog meters as well as single function meters such as voltmeters, ammeters,
wattmeters, varmeters, frequency-meters, powerfactor-meters, energy-meters, etc.
4. PRELIMINARY VERIFICATION
NOTE. At the opening of the box, check that the instrument has not been damaged during
transport.
If the instrument appears to be damaged, contact the technical after-sales service.
The box contains:
the instrument•
the user manual•
