AlgoLaser DIY KIT MK2 - Page 28

10 / 11
Insert the cable connectors into the Limit Switches, Motors, and Laser Module Sockets in the sequence
shown in the picture.
Assemble the Main Cable
Insert the motor in the correct orientation as shown in Figure 2. The limit switch can be
inserted in either direction without concern; just insert it directly.
3
1
2
4
