3.2 How to Find Focus
ALM-10BD(10W) ALM-20BDU(20W)
ALM-5BD(5W)
Place the Focus Assist on the engraving material, ensuring it is positioned beneath the laser module.
Gently slide the laser module downward until its edge lightly touches the circular disc on the bottom of
the Focus Assist. Once in this position, tighten the Thumb Screw of the laser module to secure it.
Finally, remove the Focus Assist from underneath the laser module.
Focus Assist * 1
27
