ALM-10BD(10W)
①Remove the magnetic cover
②Use M2.0 Allen Key to rotate and remove the air nozzle
③Remove the old lens and replace it with a new one
④Finally restore it in order
How to Replace the Lens
M2.0 Allen Key
① ③ ④②
Please note that the M2.0
Allen Key must be used
to remove and install
the air nozzle.
Using your hands directly
may cause damage to the
air nozzle.
29
