Alienware m17 R5 AMD Setup And Specifications

Table 13. Touchpad specifications (continued)
Description Values
Touchpad gestures For more information about touchpad gestures available
on Windows, see the Microsoft knowledge base article at
support.microsoft.com.
Power adapter
The following table lists the power adapter specifications of your Alienware m17 R5 AMD.
Table 14. Power adapter specifications
Description Option one Option two Option three
Type
180 W 240 W 240 W SFF
Connector dimensions:
External diameter
7.40 mm 7.40 mm 7.40 mm
Internal diameter
5.10 mm 5.10 mm 5.10 mm
Power-adapter dimensions:
Height
30 mm (1.18 in.) 25.40 mm (1 in.) 23 mm (0.91 in.)
Width
76.20 mm (3 in.) 100 mm (3.94 in.) 78 mm (3.07 in.)
Depth
155 mm (6.10 in.) 200 mm (7.87 in.) 152 mm (5.98 in.)
Input voltage
100 VAC–240 VAC 100 VAC–240 VAC 100 VAC–240 VAC
Input frequency
50 Hz–60 Hz 50 Hz–60 Hz 50 Hz–60 Hz
Input current (maximum)
2.34 A 3.50 A 3.50 A
Output current (continuous)
9.23 A 12.31 A 12.31 A
Rated output voltage
19.50 VDC 19.50 VDC 19.50 VDC
Temperature range:
Operating
0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F)
Storage
-40°C to 70°C (-40°F to
158°F)
-40°C to 70°C (-40°F to
158°F)
-40°C to 70°C (-40°F to
158°F)
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing the device
outside these ranges may impact the performance of specific components.
Battery
The following table lists the battery specifications of your Alienware m17 R5 AMD.
Table 15. Battery specifications
Description Option one Option two
Battery type
4-cell "smart" lithium-ion (64 Wh) 6-cell "smart" lithium-ion (97 Wh)
15

Alienware m17 R5 AMD Specifications

General

Processor	AMD Ryzen 9 6900HX
Operating System	Windows 11 Home
Weight	3.3 kg (7.28 lbs)
Graphics	AMD Radeon RX 6850M XT
Display	17.3-inch FHD (1920 x 1080)
Memory	32GB DDR5
Storage	1TB NVMe SSD
Battery	97Whr
Ports	HDMI 2.1
Wireless	Wi-Fi 6E
