Storage
This section lists the storage options on your Alienware m18 R1.
Your Alienware m18 R1 supports the following storage configuration:
Two M.2 2230 and two M.2 2280 slots for solid-state drive, for computers shipped with a NVIDIA GeForce RTX 4080 graphics
card
The primary drive of your Alienware m18 R1 varies with the storage configuration. The primary drive of your computer is the M.2
2280 drive where the operating system is installed.
Table 10. Storage specifications
Storage type Interface type Capacity
M.2 2230 solid-state drive PCIe Gen4 x4 NVMe, up to 64 Gbps Up to 512 GB
M.2 2280 solid-state drive PCIe Gen4 x4 NVMe, up to 64 Gbps Up to 4 TB
Media-card reader
The following table lists the media cards supported by your Alienware m18 R1.
Table 11. Media-card reader specifications
Description Values
Media-card type
One SD card slot
Media-cards supported
Secure Digital (SD)
Secure Digital High Capacity (SDHC)
Secure Digital Extended Capacity (SDXC)
NOTE: The maximum capacity supported by the media-card reader varies depending on the standard of the media card
installed in your computer.
Keyboard
The following table lists the keyboard specifications of your Alienware m18 R1.
Table 12. Keyboard specifications
Description Values
Keyboard type
RGB per key
RGB per key, backlit Cherry mechanical keyboard
Keyboard layout
QWERTY
Number of keys
United States and Canada: 102 keys
United Kingdom: 103 keys
Japan: 106 keys
Keyboard size
X=19.05 mm key pitch
Y=19.05 mm key pitch
Keyboard shortcuts
Some keys on your keyboard have two symbols on them. These
keys can be used to type alternate characters or to perform
14

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Alienware m18 R1 and is the answer not in the manual?

Alienware m18 R1 Specifications

General IconGeneral
Motherboard chipsetIntel HM770
Memory slots2x SO-DIMM
Internal memory32 GB
Memory channelsDual-channel
Memory form factorSO-DIMM
Internal memory typeDDR5-SDRAM
Maximum internal memory64 GB
Panel typeWVA
Color gamut100 %
LED backlightYes
Pixel density126 ppi
RGB color spaceDCI-P3
Display diagonal18 \
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display brightness300 cd/m²
Display resolution1920 x 1200 pixels
Native aspect ratio16:10
Maximum refresh rate480 Hz
Contrast ratio (typical)1000:1
Audio chipRealtek ALC3254
Speaker power2 W
Number of built-in speakers2
Charging port typeDC-in jack
USB 2.0 ports quantity0
Ethernet LAN (RJ-45) ports1
Power adapter barrel connector7.4 mm
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
AC adapter power330 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current4.4 A
AC adapter output voltage19.5 V
Operating shock140 G
Operating altitude-15.2 - 3048 m
Operating vibration0.66 G
Non-operating altitude-15.2 - 10668 m
Storage temperature (T-T)-40 - 65 °C
Operating temperature (T-T)0 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
Pointing deviceTouchpad
Keyboard backlit colorRGB
Antenna type2x2
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standardWi-Fi 6E (802.11ax)
Ethernet LAN data rates10, 100, 1000, 2500 Mbit/s
WLAN controller manufacturerKiller
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
SSD interfacePCI Express 4.0
Storage mediaSSD
SSD form factorM.2
Total storage capacity1000 GB
Compatible memory cardsSD, SDHC, SDXC
Front camera HD typeFull HD
Video capturing speed30 fps
Front camera resolution1920 x 1080 pixels
Front camera resolution (numeric)2.07 MP
Cables includedAC
Battery weight430 g
Battery voltage11.4 V
Battery capacity97 Wh
Battery recharge time3 h
Number of battery cells6
Color nameDark Metallic Moon
Form factorClamshell
Product typeLaptop
Product colorBlack
Market positioningGaming
Operating system installedWindows 11 Pro
Operating system architecture64-bit
Discrete graphics card modelNVIDIA GeForce RTX 4070
On-board graphics card modelAMD Radeon 610M
Discrete graphics card memory8 GB
Discrete graphics memory typeGDDR6
Processor cache64 MB
Processor cores12
Processor model7845HX
Processor familyAMD Ryzen™ 9
Processor frequency3 GHz
Processor cache typeL2 & L3
Processor manufacturerAMD
Processor boost frequency5.2 GHz
Weight and Dimensions IconWeight and Dimensions
Depth319.9 mm
Width410.3 mm
Weight4230 g
Height (rear)25.1 mm
Height (front)24.1 mm
