Alienware m18 R1 User Manual

Battery
The following table lists the battery specifications of your Alienware m18 R1.
Table 16. Battery specifications
Description Values
Battery type
6-cell lithium-ion (97 Wh)
Battery voltage
11.40 VDC (nominal)
Battery weight (maximum)
0.43 kg (0.95 lb)
Battery dimensions:
Height
7.90 mm (0.31 in.)
Width
336 mm (13.23 in.)
Depth
81.40 mm (3.20 in.)
Temperature range:
Operating
● Charging: 0°C to 50°C (32°F to 122°F)
● Discharging: 0°C to 60°C (32°F to 140°F)
Storage
-20°C to 65°C (-4°F to 149°F)
Battery operating time Varies depending on operating conditions and can significantly
reduce under certain power-intensive conditions.
Battery charging time (approximate)
NOTE: Control the charging time, duration, start and
end time, and so on using the Dell Power Manager
application. For more information on the Dell Power
Manager see, Me and My Dell on www.dell.com.
● Standard charging: 3 hours, when computer is turned off
● ExpressCharge: 2 hours, when computer is turned off
● ExpressChargeBoost: 20 minutes, from 0% up to 35% when
computer is turned off
Coin-cell battery
None
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing the device
outside these ranges may impact the performance of specific components.
CAUTION: Dell recommends that you charge the battery regularly for optimal power consumption. If your battery charge
is completely depleted, connect the power adapter, turn on your computer, and then restart your computer to reduce the
power consumption.
Display
The following table lists the display specifications of your Alienware m18 R1.
Table 17. Display specifications
Description Option one Option two
Display type
18-inch, Quad High Definition plus
(QHD+)
18-inch, Full High Definition plus (FHD+)
Touch options
Not supported Not supported
Display-panel technology
Wide Viewing Angle (WVA) Wide Viewing Angle (WVA)
17

Alienware m18 R1 Specifications

General

Motherboard chipset	Intel HM770
Memory slots	2x SO-DIMM
Internal memory	32 GB
Memory channels	Dual-channel
Memory form factor	SO-DIMM
Internal memory type	DDR5-SDRAM
Maximum internal memory	64 GB
Panel type	WVA
Color gamut	100 %
LED backlight	Yes
Pixel density	126 ppi
RGB color space	DCI-P3
Display diagonal	18 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	300 cd/m²
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Maximum refresh rate	480 Hz
Contrast ratio (typical)	1000:1
Audio chip	Realtek ALC3254
Speaker power	2 W
Number of built-in speakers	2
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Power adapter barrel connector	7.4 mm
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
AC adapter power	330 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	4.4 A
AC adapter output voltage	19.5 V
Operating shock	140 G
Operating altitude	-15.2 - 3048 m
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Pointing device	Touchpad
Keyboard backlit color	RGB
Antenna type	2x2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
WLAN controller manufacturer	Killer
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express 4.0
Storage media	SSD
SSD form factor	M.2
Total storage capacity	1000 GB
Compatible memory cards	SD, SDHC, SDXC
Front camera HD type	Full HD
Video capturing speed	30 fps
Front camera resolution	1920 x 1080 pixels
Front camera resolution (numeric)	2.07 MP
Cables included	AC
Battery weight	430 g
Battery voltage	11.4 V
Battery capacity	97 Wh
Battery recharge time	3 h
Number of battery cells	6
Color name	Dark Metallic Moon
Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Gaming
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Discrete graphics card model	NVIDIA GeForce RTX 4070
On-board graphics card model	AMD Radeon 610M
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR6
Processor cache	64 MB
Processor cores	12
Processor model	7845HX
Processor family	AMD Ryzen™ 9
Processor frequency	3 GHz
Processor cache type	L2 & L3
Processor manufacturer	AMD
Processor boost frequency	5.2 GHz

Weight and Dimensions

Depth	319.9 mm
Width	410.3 mm
Weight	4230 g
Height (rear)	25.1 mm
Height (front)	24.1 mm
