OVERVIEW OPERATION
1. LED Indications
The top LED shows the current radio status.
LED Indication
Status
Flashes Red
Low battery voltage
Constant Red
Transmitting
Constant Green
Analog Receiving
Constant Cyan
Digital Receiving
Flashes Green
Scan
2. Programmed Key
There are two programmable keys ([PF1], [PF2]) at the right side of radio. it can be
assigned functions by manually set in radio or set by PC software.
Manually set by radio: Press ( MENU) key then move cursor to setting Radio
Set  move to Menu set 34-37 select the [PF1] or [PF2] then assign functions, there
are 2 definition of assigning a key, short press and long press (hold they key for a
while).
Set by PC software: Open software, go to Public Optional Key function then
select the desired functions. Assigned different functions are listed in the list below.
OFF
No Function
Voltage
Check the current battery capacity voltage
Power
Switch the power between super high, high, middle and low
