7 Upgrading the controller
© 2021 Interflex Datensysteme GmbH IF-4072 Controller 21
7 Upgrading the controller
The functional scope of a controller depends on the purchased license. You can extend (upgrade) this
license, if necessary.
Example: Upgrading an IF-4070 controller with 8 terminals to a controller with 16 terminals
After ordering an upgrade, you will receive two files from Interflex:
Batch file s_tclicence.bat
License file *.xml
When entering the name of the license file, note that it is case-sensitive.
Performing the upgrade
u Start cmd.exe and execute the batch file s_tclicence.bat.
The license is automatically copied to the controller where it is activated.
The application is restarted.
8 Technical specifications
General data
Fuse Self-resetting PTC fuse
Power consumption Approx. 13 VA
Interfaces
Service interfaces Ethernet network connection with SSH
RS232 with 115200 baud, 8 bits, no parity, 1 stop
Inputs 4 inputs for floating status contacts.
Debounce time of contacts at least 100 ms
Output relay/switching capacity 2 relays with “normally open” (NO) and “normally closed” (NC)
contacts
switching capacity up to 30 V, 2 A
General data
Degree of protection IP20
Protection category III
Dimensions (H x W x D) 160 x 90 x 58 mm
