WZ
3
14:4:2 Left PCB up-issue to iss.2
ECN No: 1043
Assembly No(s): 003-212 iss.1
Date: June 26
h
2004
Reason: Stabilise performance of pink noise cct
Details of change:
Assy 003-212, PCB AG5397 iss.1
Up-issue PCB to issue 2
2 value changes and one additional component.
Via sizes increased to 1.25mm with 0.6mm holes except a few which had to be
1.1mm dia with 0.6mm holes.
4 bar LED footprint updated.
Issue 2 PCBs fitted from serial no. 065964
