ALLEN & HEATH Qu-32 User Manual

Qu Mixer User Guide 9 AP9372 iss.4
3.3 Differences between the Qu models
All three models operate in the same way and have a similar touch screen menu structure. The
larger models add Groups and Matrix. Other differences are shown here:
Shelf for iPad 10 SoftKeys 2 Group masters 2 Matrix masters
Extra FX Send and Group Mix selects 24 fader strips
4 SoftKeys
16 fader strips
LED colour strips to identify layer
32 fader strips
4 Group masters 2 Matrix masters 4 DCA Group masters
Extra 2 Group Mix selects
Larger Touch Screen

ALLEN & HEATH Qu-32 Specifications

General

Sample rate	48 kHz
Channels quantity	32 channels
Digital sound processing	- bit
DJ mixer	-
USB port	Yes
Product color	Black
USB connector type	USB Type-B
XLR out	2
Master (XLR) out	24
RJ-45 ports quantity	1
Power consumption (typical)	- W
Output impedance	75 Ω

Weight and Dimensions

Depth	471 mm
Width	849 mm
Height	190 mm
Weight	20000 g
Package type	Box
Package depth	680 mm
Package width	1000 mm
Package height	350 mm
Package weight	24000 g
